ARM ARM7TDMI - Table 7-1 General Timing Parameters

AC and DC Parameters
7-4 Copyright © 2001, 2004 ARM Limited. All rights reserved. ARM DDI 0210C
The timing parameters used in Figure 7-1 on page 7-3 are listed in Table 7-1.
Table 7-1 General timing parameters
Symbol Parameter Parameter type
T
addr
MCLKr to address valid Maximum
T
ah
Address hold time from MCLKrMinimum
T
bld
MCLKr to MAS[1:0] and LOCK Maximum
T
blh
MAS[1:0] and LOCK hold from MCLKrMinimum
T
cdel
MCLK to ECLK delay Maximum
T
exd
MCLKf to nEXEC and INSTRVALID valid Maximum
T
exh
nEXEC and INSTRVALID hold time from
MCLKf
Minimum
T
mdd
MCLKr to nTRANS, nM[4:0], and TBIT valid Maximum
T
mdh
nTRANS and nM[4:0] hold time from MCLKrMinimum
T
msd
MCLKf to nMREQ and SEQ valid Maximum
T
msh
nMREQ and SEQ hold time from MCLKfMinimum
T
opcd
MCLKr to nOPC valid Maximum
T
opch
nOPC hold time from MCLKrMinimum
T
rwd
MCLKr to nRW valid Maximum
T
rwh
nRW hold time from MCLKrMinimum
