Debug in Depth
B-50 Copyright © 2001, 2004 ARM Limited. All rights reserved. ARM DDI 0210C
B.14 Programming watchpoints
To make a watchpoint unit cause watchpoints on data accesses:
1. Program its address value register with the address of the data access to be
watchpointed.
2. Program the address mask register to
0x00000000
.
3. Program the data value register if you require a data-dependent watchpoint. (A
data-dependent watchpoint is one that matches the data value read or written as
well as the address.) Ensure that you clear all the bits in the data mask register.
If the data value is not required, program the data mask register to
0xFFFFFFFF
(all
bits set).
4. Program the control value register as follows:
• nOPC = 1
• nRW = 0 for a read or nRW = 1 for a write
• program MAS[1:0] with the value corresponding to the appropriate data
size.
5. Program the control mask register as follows:
• nOPC = 0
• nRW = 0
• MAS[1:0] = 0
• all other bits set.
You can set nRW, or MAS[1:0] when both reads and writes, or data size accesses
are to be watchpointed respectively.
6. If you wish to make the distinction between User and non-User mode data
accesses, program the nTRANS bit in the control value and control mask
registers accordingly.
7. If required, program the EXTERN, RANGE, and CHAIN bits in the same way.
Note
The above are examples of how to program the watchpoint register to generate
breakpoints and watchpoints. Many other ways of programming the registers are
possible. For instance, you can provide simple range breakpoints by setting one or more
of the address mask bits.
