Debug in Depth
ARM DDI 0210C Copyright © 2001, 2004 ARM Limited. All rights reserved. B-41
24 D[23] Input/output
25 D[24] Input/output
26 D[25] Input/output
27 D[26] Input/output
28 D[27] Input/output
29 D[28] Input/output
30 D[29] Input/output
31 D[30] Input/output
32 D[31] Input/output
33 BREAKPT Input
Table B-4 Scan chain 1 cells (continued)
Number Signal Type
