13-52 BE1-951 Testing and Maintenance 9328900990 Rev L
Command Purpose
SL-N=MODE3 Sets MODE3 as custom logic name.
SL-243=3 Sets 243 switch for Mode 3 operation.
SL-VO1=243 Enables OUT1 to close for 243.
EXIT;Y Exit and save settings.
Step 2: Prepare to monitor the virtual switch operation. An ohmmeter or continuity tester may be used
to monitor the contact status of OUT1.
Step 3: Transmit the commands in
Table 13-83 to the relay. These commands pulse the 243 Switch on
and off once.
Result: OUT1 contact closes for 200 milliseconds and returns to the open state.
Table 13-83. x43 Mode 3 Pulse Commands
Command Purpose
A= Gains write access.
CS-243=P Selects 243 for Pulse operation.
CO-243=P Executes 243 for Pulse operation.
Virtual Breaker Control Switch (101)
Purpose: To verify 101 virtual breaker control switch operation.
Reference Commands: SL-101, CS/CO-101C, CS/CO-101T
Step 1: Prepare the 101 Virtual Breaker Control Switch for testing by transmitting the commands in
Table 13-84 to the relay.
Table 13-84. 101 Virtual Breaker Control Switch Test Commands
Command Purpose
A= Gains write access.
SL-N=NONE Zero out custom logic settings. Overwrite with LOGIC=NONE settings.
Y Confirm overwrite.
SL-N=S101 Sets S101 as custom logic name.
SL-101=1 Enables 101 Switch.
SL-VO1=101T Enables OUT1 to close when 101T is TRUE.
SL-VO2=101C Enables OUT2 to close when 101C is TRUE.
SL-VO3=101SC Enables OUT3 to close when 101SC is TRUE.
EXIT;Y Exit and save settings.
Step 2: Prepare to monitor the 101 Virtual Breaker Control Switch operations. Operation can be verified
by monitoring the programmed output contacts, HMI Screen 2.2.1 or by using RG-STAT
command. See Section 6, Reporting and Alarm Functions, for more information.
Step 3: Transmit the commands in
Table 13-85 to the relay. These commands place the 101 Switch in
the trip position.
Result: OUT1 closes for 200 milliseconds and returns to the open state. OUT3 opens (trip state)
and remains open.
