BCS Line User Manual

160
1) Click
Add
.
Figure 4-168
2) Configure parameters.
Table 4-52
Parameter Description
Type
Fisheye + PTZ:
● 1 Fisheye + 1 PTZ
● 1 Fisheye + 2 PTZ
● 1 Fisheye + 3 PTZ
Scene Name This parameter is user defined.
Master Camera
Select a fisheye camera as needed.
1. Click
Select
in
Master Camera
line.
2. Select a fisheye camera in the prompted dialog box.
3. Click
Apply
.
Slave Camera
Select speed domes as needed.
1. Click
Select
in
Master Camera
line.
2. Select speed domes in the prompted dialog box.
3. Click
Apply
.
Step 3 Click
Apply
.
The monitoring area is successfully added.
