Default settings D 2
ekrPro Com
60
web guide controller EDV-No.: MD.191.01.05/1.6.x Chapter: D2
with analog sensors Date: 23.11.2007 Page: 2/6
Menu Parameter Level 1 Parameter Level 2 Parameter Level 3
Default Value
FVG
Connection
Op. Mode
not connected
Int. FVG
Homing Dir. Homing dir. inv. not reversed
Ref. switch inv. not reversed
Offset 1
Offset [mm] 0
Inverted no
Offset 2
Offset [mm]
2000ht/Dark
Inverted yes
Range Range [mm] 5000.0
FVG sensor
adjustment
unit
Only for internal
FVG!
Feed Feed in µm / rev. 20088
(for 4,2:1 gear box)
FVG 1
Homing Dir. Homing dir. inv. not reversed
Ref. switch inv. not reversed
Offset Offset [mm] 0
Inverted no
Range Range [mm] 5000.0
Feed Feed in µm / rev. 20088
(for 4,2:1 gear box)
FVG 2
Range Homing Dir. Homing dir. inv. not reversed
Ref. switch inv. not reversed
Offset Offset [mm] 2000
Inverted yes
Range Range [mm] 5000.0
Ext. FVG
Only for internal
FVG!
Feed Feed in µm / rev. 20088
(for 4,2:1 gear box)
Retract mode Select a full retract mode SC & Man.
Norming mode Select a norming mode Bright/Dark
Width Adjust. FVG width adjustment
Level outer
active
Width adj. lvl. [%]
75
Repositioning FVG remembers current
position after:
Tear Off not active
SC or Man
not active
Velocities
Retract vel. [mm/s]
60
Edge push vel. [mm/s] 5
Slow man. vel. [mm/s]
1
Fast man. vel. [mm/s]
60
Norm. vel. [mm/s]
60
Special Mode after error Man.
FVG
General part
Sensor Cover Guarding not active
