BST ekrPro Com60 - Page 154

Default settings D 2
ekrPro Com
60
web guide controller EDV-No.: MD.191.01.05/1.6.x Chapter: D2
with analog sensors Date: 23.11.2007 Page: 3/6
Menu
Parameter Level 1 Parameter Level 2 Parameter Level 3 Default Value
Ref. Width [Press “set ref”!] 0
Limits Nominal width 80.0
Error E- -5.0
limits E+ +5.0
Warning W- -2.0
Width Measure
limits W+ +2.0
Edge 1 Device This device
Edge Sensor 1
Inverted off
Normed active
Edge 2 Device This device
Edge Sensor 2
Inverted active
Normed active
Edge 3 Device This device
Edge Sensor 3
Inverted off
Normed active
Src. SC Device This device
Edge SC
Inverted off
Normed off
Src. EFE Device This device
Edge EFE
Inverted off
Edge Sources
Normed active
