Daedong DSC48 - Page 102

2
-26
Apr. 2007
DSC48
K. CONNECTING ROD
Item Factory specifi cation Allowable limit
Connecting rod misalignment
-
0.05 mm
0.0020 in.
Clearance between piston pin and piston pin bushing 0.014 ~ 0.038 mm
0.00055 ~ 0.00150 in.
0.15 mm
0.0059 in.
Piston pin O.D. 25.002 ~ 25.011 mm
0.98433 ~ 0.98469 in.
-
Piston pin bushing I.D. 25.025 ~ 25.040 mm
0.98524 ~ 0.98583 in.
-
L. CONNECTING ROD
Item Factory specifi cation Allowable limit
Crankshaft misalignment
-
0.08 mm
0.003 in.
Clearance between crankshaft and crankshaft bearing 1 0.040 ~ 0.118 mm
0.00157 ~ 0.00465 in.
0.20 mm
0.0079 in.
Crankshaft journal O.D. 51.921 ~ 51.940 mm
2.04414 ~ 2.04489 in.
-
Crankshaft bearing 1 I.D. 51.980 ~ 52.039 mm
2.04646 ~ 2.04878 in.
-
Clearance between crankshaft journal and crankshaft
bearing 2
0.040 ~ 0.104 mm
0.00157 ~ 0.00409 in.
0.20 mm
0.0079 in.
Crankshaft journal O.D. 51.921 ~ 51.940 mm
2.04414 ~ 2.04489 in.
-
Crankshaft bearing 2 I.D. 51.980 ~ 52.025 mm
2.04646 ~ 2.04823 in.
-
Clearance between crank pin and crank pin bearing 0.025 ~ 0.087 mm
0.00098 ~ 0.00343 in.
0.20 mm
0.0079 in.
Crank pin O.D. 46.959 ~ 46.975 mm
1.84876 ~ 1.84947 in.
-
Crank pin bearing I.D. 47.000 ~ 47.046 mm
1.85040 ~ 1.85221 in.
-
Crankshaft side clearance 0.15 ~ 0.31 mm
0.0059 ~ 0.0122 in.
0.5 mm
0.020 in.
