Daedong DSC48 - VERTICAL ADJUSTMENT OF FEEDING DEPTH CONTROL CHAIN

3
-22
Apr. 2007
DSC48
1
1
2
A
A
C
B
1.5.16 VERTICAL ADJUSTMENT OF
FEEDING DEPTH CONTROL CHAIN
417W347A
(1) Prop
(2) Chain plate
(A) 6 ~ 9 mm
(B) Adjust with the turnbuckle
(C) Clearance between the prop and chain plate when the feeding depth control chain is at deepest position
