Apr. 2007
7
-5
DSC48
2.1 OVERVIEW
The alarm buzzer, lamps on the instrument panel, and
automatic engine stop function operate to prevent any
problems during work.
The operation of the charge lamp and engine oil lamp are
irrelevant to the MICOM since they come on and go out ac-
cording to the condition of the alternator or engine oil switch.
The alarms, warning lamps and automatic engine stop
function, except the coolant temperature alarm, are con-
trolled by the MICOM unit.
However, the threshing unit controller determines whether
to send electric signal and turn on the coolant temperature
warning lamp. The MICOM unit only determines whether
to sound the front buzzer.
2.
ALARM BUZZER, LAMPS ON INSTRUMENT PANEL AND AUTOMATIC ENGINE STOP FUNCTION
Symptom Alarm Instrument panel Automatic engine stop function
Feeding chain clogging alarm ΟΟ Ο
Straw discharging chain
clogging alarm
ΟΟ Ο
No. 1 alarm ΟΟ -
No. 2 alarm ΟΟ -
Grain alarm ΟΟ -
Coolant temperature alarm ΟΟ -
Reverse driving alarm Ο --
Load alarm ΟΟ -
Grain sensor alarm Ο --
Check lamp - Ο -
Charge lamp - Ο -
Oil lamp - Ο -
Ignition switch - - Ο
