1.3.3 COMPONENTS RELATED TO
CUTTING BLADE DRIVE CASE
When installing the drive case assembly, make sure to
align the mating surface of the bearing holder.
- Align with the spline boss in the case.
417W312A
(1) Cutting blade drive case
(2) Cutting blade drive case connection
(3) Bolt (LOCTITE applied)
417W313A
(1) Cutting blade crank
