• When replacing parts, be sure to install the appropriate
safety decal as well. Otherwise, the customer's safety
will be threatened.
• If a decal is damaged or detached, always replace with
the appropriate decal.
• The decal and its attaching location are as follows.
• Part numbers appear at the bottom of decals.
12.1 LOCATION OF DECALS
417O121A
(1) Label, muffl er warning
(2) Label, radiator
(3) Label, caution(fan)
(4) Label, muffl er
(5) Label, fuel warning
(6) Label, joystick lever
(7) Label, safety
(8) Label, coupler socket
(9) Label, ass’y
(10) Label, PTO caution
(11) Label, ROPS warning
(12) Label, ROPS caution
12. SAFETY DECALS
20
13
17
7
81018
9
12
11
12
3
12
4
3
12
16
22
19
26
1
5
21
31
25
14
4
6
28
24, 26
30
29
15
27
2
