Apr. 2007
1
-25
DSC48
1.9.4 EVERY 50 HOURS
A. CLEANING AIR CLEANER ELEMENT
1. When dry dust is accumulated on the element, blow
compressed air from the inside to the upper and lower
sides to remove the dust.
2. When carbon or oil is stuck to the element, use deter-
gent to remove them.
3. The element should be checked every day.
417W164A
417W165A
N. ADJUSTING STRAW DISCHARGE WIRE
417W163A
(1) Adjusting bolt (A) Stretch: 5 mm
Wire spring extension 5 mm (0.197 in.)
