1.5.2 LIQUID GASKET APPLICATION
Apply liquid gasket (Three Bond 1215 or equivalent) to the following parts.
Section LOCTITE application
Driving unit
• Brake case gasket
• Transmission case gasket
• Vehicle speed sensor gasket
• Rubber cap and oil seal of reaping drive pulley
• Seal plug on the end of No. 1 shaft of the transmission case (LH)
• Rubber caps on front and rear wheels
• Assembled surface of plug and main frame, cap of drive roller
• Cap at end of 20 bevel gear shaft on right side of oil tank
• Gaskets of oil tank and pipe joint
