Daedong DSC48 - INSTALLATION OF CHAIN LOCK PLATE; INSTALLATION OF STEM SIDE PROP

3
-20
Apr. 2007
DSC48
1
2
A
A
1.5.11 INSTALLATION OF CHAIN LOCK
PLATE
417W341A
(1) Anti chain lock plate
(2) Feeding guide
(3) Feeding chain
(A) 2.8 ~ 3.2 mm
1.5.12 INSTALLATION OF STEM SIDE
PROP
(A) 26 ~ 34 mm
(1) Stem side prop
(2) Feeding chain
(A) Fixed with bolt
417W342A
417W343A
