Symbol Definition Chapter 1 - Introduction
Apollo Operator’s Manual 13
Part Number: 90 38 237, 6th edition
Symbol Definition
The following symbols appear on the Apollo and are
defined below.
Symbol Meaning
Suppress alarm tone for 2 minutes; change
priority of technical alarms and
acknowledge them
Display standard screen
Display the three monitoring screens in
succession
Standby/operation switch
Access more user options/screens
Pulse rate
Action in progress
Upper and lower alarm limits
Upper alarm limit only
Lower alarm limit only
Alarm monitoring inactive
O
2
alarm disabled (no valid CO
2
breath)
Upper and lower alarm limits disabled
Upper alarm limit disabled
Lower alarm limit disabled
Alarm limit disabled
4-digit password entered
Protection class type B (body)
u
g
_
>
<
--
****
m
Protection class type BF (body floating)
Connection for equipotential bonding
Attention: consult accompanying
documents.
Close menu, return to preceding menu
Non-rebreathing system at common gas
outlet
Remaining battery power for the internal
uninterruptible power supply (UPS)
Manual ventilation
Automatic ventilation
Connector for piped medical gas supply
Backup gas cylinder
UL test mark
Plug system for Vapor units
Electrostatic device (ESD) sensitivity
Connection for halogen lamp
Surface hot; do not touch.
Symbol Meaning
m
P
z
r
xx%
