Dräger Apollo Operating Instructions

Chapter 6 - Operation Summary Activating the CO2 Bypass Function (Optional)
80 Apollo Operator’s Manual
Part Number: 90 38 237, 6th edition
Activating the CO
2
Bypass
Function (Optional)
Figure 58. Release Button on CLIC Adapter• To activate the CO2 bypass function, press the
release button (1 in Figure 58); the disposable
absorber swings open on its mounting. The
breathing system is sealed at the same time
and ventilation continues.
Figure 59. Pushing CLIC Adapter Back into Place• To deactivate the CO2 bypass function, swing
the disposable absorber (2 in Figure 59) back
into the system until it engages.
1
WARNING !
CO
2
is not absorbed in the breathing system
when the absorber is swung out.
2
