Dräger Apollo

Chapter 7 - Ventilation Volume-Controlled Ventilation
90 Apollo Operator’s Manual
Part Number: 90 38 237, 6th edition
Table 4. Adjustment ranges and factory default values
for volume mode parameters
2. Press the soft key for the parameter to be
changed; its color changes to yellow to indicate
that it’s selected.
3. Turn the confirm knob to adjust the parameter to
the desired value, and press the knob to confirm
(4 in Figure 64).
Continue to set the values for the other
parameters.
The parameters that can be set for volume mode
are shown in Table 4, along with their adjustment
ranges and factory default values.
Starting the Volume Ventilation Mode
4. When all the parameters have been preset,
press the confirm knob to start volume ventilation
(4 in Figure 64).
The parameter soft keys turn green and display
the preset parameter values. The “Volume”
indication in the status field stops flashing and is
displayed continuously. Volume ventilation
begins.
If a volume parameter has to be changed during
ventilation:
• Press the soft key for the
parameter to be changed, turn
the confirm knob to the desired
value, and press knob to
confirm.
Note: Volume mode can also be started without
presetting values:
• Press the >Vol Mode< key
located at the bottom of the
display panel, and press the
confirm knob. Default parameter
values are used.
Note: There is 15-second timeout period for
making ventilation mode changes, with a
5-second audible tone sequence after the
first 10 seconds. If the new setting is not
confirmed within the timeout period, the
current ventilation setting remains in effect.
Ventilation
parameter
(volume mode)
Adjustment
range
Factory default
value
1
1. Site defaults can be set instead.
Pressure limitation
>P
MAX< [cmH
2
O]
10 to 70
min. PEEP +10
40
Tidal volume
>VT< [mL]
20 to 1400
2
2. Optionally 10 to 1400 mL.
600
Frequency
>Freq<
3,4
[bpm]
3. Depending on the configuration, the inspiratory time (TINSP) can be
automatically changed together with adjustment of the frequency so
that the resultant ratio of inspiration to expiration (I:E) remains
constant. Only applies if trigger = OFF. See the “Configuration”
chapter.
3 to 80 12
>TINSP<
4
[sec.]
4. The resultant ratio of inspiration to expiration (I : E) is also displayed
in parallel.
0.2 to 6.7 1.7
Insp. pause time :
insp. time
>T
IP : TINSP< [%]
0 to 60 10
>PEEP< [cmH
2
O] 0 to 20
max. PMAX –10
0
Trigger sensitivity
>Trigger< [L/min]
OFF,
0.3 to 15
3.0 (Press.
Supp. Mode)
OFF (Vol./
Press. Mode)
Pressure support
>∆P
PS<
5
[cmH
2
O]
5. Optional.
OFF,
3 to 50
max. P
MAX–PEEP
5 (Press
Supp. Mode)
OFF (Vol./
Press. Mode)
Rise time
>TSLOPE< [sec.]
0.0 to 2.0 0.0
>Age< [years] <1 to 120 40
Ideal body weight
>Weight<
5
[kg/lb]
1 to 120 kg,
1 to 240 lb
--
