Dräger Apollo Operating Instructions

SpO2 Measurement (Optional) Chapter 8 - Monitoring
Apollo Operator’s Manual 127
Part Number: 90 38 237, 6th edition
SpO
2
Measurement (Optional)
Selecting a Sensor
Only Nellcor sensors may be used (see the
Accessories List, P/N 8603528) for list of available
sensors).
The new Oximax modules implemented in the Apollo
are only compatible with the new Oximax sensors
(purple probe or white probe for MAX FAST).
Only the DEC-8 or DEC-4 extension lead (purple
plug connector) may be used.
The new sensors are backward-compatible with all
modules already used in the field in older Dräger
machines.
The following table provides guidelines for selecting
a specific sensor.
DURASENSOR™ and OXIMAX™ are registered trademarks.
WARNING !
Follow the Instructions for Use for the SpO
2
sensor being used. Incorrect positioning may
cause injuries.
Sensor type:
OXIMAX™
MAX N
OXIMAX™
MAX I
OXIMAX™
MAX P
DURASENSOR™
DS-100 A
OXIMAX™
MAX A
OXIMAX™
MAX R
OXIMAX™
MAX FAST
Age group
Neonates/
Adults
Infants Children Adults
Weight
of the patient
<3 to >40 kg
(<6.6 to >88 lb)
1 to 20 kg
(2.2 to 44 lb)
10 to 50 kg
(22 to 110 lb)
>40 kg
(>88 lb)
>30 kg
(>66 lb)
>50 kg
(>110 lb)
>40 kg
(>88 lb)
Duration
of use
Short and long-term monitoring Short-term
monitoring
Short and long-term monitoring
Mobility
of the patient
Limited activity Inactive patients
only
Limited activity Inactive
patients only,
must be
checked at
least every 8
hours
Limited
activity
Preferred
measuring
point
Ball of the foot Toe Finger Nose Forehead
Sterility
a
Sterile
packaging
Sterile
packaging
Sterile
packaging
––––––– Sterile
packaging
Sterile
packaging
Sterile
packaging
a. In unopened and undamaged packaging
