Removal–refitting of the engine assembly
file:///D|/Manuales/Para%20recolocar/MOTOS/DUCATI/DUCATI/M796/wsm/EN/M796_ABS_11_9_1.64.1.html[11/12/2015 18:40:43]
Refit the oil cooler to the frame 9 - 2.2, Refitting the oil cooler
Refit the throttle body 8 - 6, Refitting the throttle body
Connect the throttle cable 7 - 8.1,
Refitting the throttle
twistgrip
Refit the airbox 8 - 7,
Refitting the airbox
Refit the ABS control unit 7 - 6,
Refitting the ABS control unit
Reconnect the HT leads 6 - 12,
Spark plug
Connect the starter
motor/solenoid cable
6 - 3,
Refitting the starter motor
Connect ECU connector to main
wiring harness
6 - 12,
Refitting the electronic control
unit
Refit the battery support 6 - 2,
Battery support
Refit the battery 6 - 2,
Refitting the battery
Refit the fuel tank 8 - 2,
Refitting the fuel tank
Refit the tank covers 5 - 2,
Refitting the fuel tank fairings
Refit the seat 5 - 3,
Refitting the seat
