b Press Section
chap.2
bPress Section
1. Description
Drum
Drum driving gear
Cam
Press roller
Press lever
P roll sensor
Contact pressure mortor
Contact pressure lower limit switchHi contact pressure limit switch Contact pressure upper limit switch
