167
z Exterior
chap.3
43SH0310
1) Remove the control panel.
2) Remove the 5 screws indicated. Then remove the
2 connectors.
3) Remove the 17 screws from the panel PCB, and
remove the panel PCB.
Mounting angle
Screw
Screws
Screw
Screws
Panel PCB
<<S-type>>
