290
x Overview
chap.7
x Overview
¡Failure to heed the above could result
in crushed or otherwise injured
hands or fingers.
The Duprinter's HELP modes can be broadly classified into the
following types:
â—† Modes for ROM version display / version upgrade
These modes display the version numbers of the main PCB unit's
ROM (U33), the I/F PCB unit's ROM (U10) and permit version
upgrade of the main PCB unit's U33 ROM.
â—† Modes for adjustment / specification setting
These modes set the functioning of variable resistors and switches
by using the battery PCB unit's EEPROM to memorize settings
made on the operation panel. All of these adjustments and settings
are made at the factory prior to shipment of each Duprinter.
¡New adjustments and appropriate settings must
be made after the battery PCB unit is replaced and after
initialization setting has been implemented (using HELP mode
H-27).
â—† Modes for function checks
These modes permit the running of function checks on:
individual motors, given series of operations, and electrical
circuits.
When these modes are used to check motor functioning, the
motor being checked is run by itself, but interlocks are
suspended. When such checks are run, take care not to put
hands or fingers in motor-related moving parts that could start
up unexpectedly.
â—† Modes for sensor and switch displays
These modes provide displays of the conditions of sensors and
switches.
â—† Modes for total count displays
These modes provide displays of the counts of the total number of
plates made and sheets printed by the Duprinter since it was
manufactured. They also permit resetting of the total count values
displayed in the user mode.
IMPORTANT
