Code display Cause Detection timing
E001
• The main motor (M1) is defective.
• The main motor PCB Unit is defective.
• The main PCB Unit is defective.
• The encoder sensor (PS7) is defective.
• While the drum rotation signal is lit, the encoder sen-
sor (PS7) cannot detect the edge for 1 second.
E002
• The elevator motor (M2) is defective.
• The elevator top limit sensor (PS9) is defective.
• The elevator bottom limit switch (MS6) is defective.
• The drive PCB is defective.
- The main PCB Unit is defective.
• The elevator operation is defective.
• The elevator does not reach the top limit for 9 sec-
onds after the elevator motor (M2) up signal is lit.
• The elevator does not reach the bottom limit for 9
seconds after the elevator motor (M2) down signal
is lit.
E003
• The cutter motor (M5) is defective.
• The cutter limit on the operation side (MS1) is defec-
tive.
• The cutter limit on the rear side (MS2) is defective.
• The drive PCB is defective.
• The main PCB unit is defective.
• The master jams in the cutter unit section.
• The cutter motor does not reach the moved cutter
limit switch for 3 seconds after the cutter motor dri-
ving signal is lit.
E004
• The lamp is defective.
• The invertor unit is defective.
• The CCD is defective.
• AD PCB unit is defective.
• Main PCB unit is defective.
• In the lamp lighting check, amount of light received
by CCD does not reach regulation value. (Perform
the lamp lighting check once only, with the power
turned on.)
E005 • The ink roller rise/descent motor is defective.
• The motor does not reach the relevant switch within
15 seconds of sending of the ink roller rise/descent
motor drive signal.
E006 • The contact pressure motor is defective.
• The motor does not reach the relevant switch within
25 seconds of sending of the contact pressure
motor rotation signal.
