89
z Scanner Section
chap.2
Platemaking Area for the Book Shadow Erasing Mode
When the platemaking is performed in the book shadow erasing mode, the platemaking area is limited 3
mm inner than the normal platemaking area as shown in the figure. 15mm is left in the central section
(stitching section).
* During multiple image printing or when paper size is set to A4, the book shadow erasing mode can not
be used.
Platemaking Area for the Selected Paper
2The platemaking area varies depending on the selected paper size as shown below.
: DP-43E/S, 33E/S, 31E/S
* When the magnification error is 0 in the primary
scanning direction or in the secondary scanning
direction, the size for the same size (1:1) platemak-
ing is shown.
NOTE
To Next Page
