x Scanner Section
chap.3
(1)
Removing the Vertical Size Scale Plate
1) Remove 2 screws to take out the vertical size
scale plate.
: Do not dirt the shading plate.
Clean it if it is dirty.
IMPORTANT
Vertical size scale plate
Vertical size scale plate
Vertical size scale plate
Shading plate
Shading plate
Glass
ADF is attachedADF is not attached
Screws
x Scanner Section
¡ Put it between the frame and glass to attach.
Match it with the frame standard face, leave a
play on the operation side and tighten the
screws.
Reinstallation
NOTE
To Next Page
