Chap.1 ⁄0 Error Messages and Corrective Action
53
If the message "PAPER JAM ON THE FEEDER SIDE" is
indicated in the error display panel, check the feeder side and
remove the jammed paper by following the procedure below.
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Press the paper tray descending switch to lower
the paper tray slightly.
The paper tray is lowered for the time that the
switch is pressed.
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Pull out the jammed paper as shown in the
diagram.
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Press and hold the JOG switch until the drum
comes to a stop with a beep.
WARNING
• Do not touch the drum or rollers when you
operate the JOG switch.
• Do not put your hands or fingers inside the
machine while it is operating. Your hands
may be pulled in or nipped.
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
(6) Paper Jam (Feeder Side)
Paper tray descending switch
PAPER JAM ON THE FEEDER SIDE
JOG switch
(Drum rotator switch)
To Next Page
