Duplo Duprinter DP-43S User Manual

141
b Press Section
chap.2
When the power is turned on, the standard contact pressure position is sensed by checking contact pressure
position in the sequence described below.
2If low limit contact pressure>hi limit:
2If hi limit contact pressure>maximum limit:
2If contact pressure = maximum limit:
2. Sensing of standard contact pressure position when power is turned on
Sequence
Contact pressure motor
Contact pressure maximum
limit switch
Contact pressure hi
switch
Contact pressure low
limit switch
Low limit = switch ON
Contact pressure standard
Power switch ON
Sequence
Contact pressure motor
Contact pressure maximum
limit switch
Contact pressure hi
switch
Contact pressure low
limit switch
Contact pressure standard
Power switch ON
Sequence
Contact pressure motor
Contact pressure maximum
limit switch
Contact pressure hi
switch
Contact pressure low
limit switch
Contact pressure standard
Power switch ON
Standard
Lower limit
Press roller
Drum
Drum
Drum
Upper
limit
Hi
Press roller
Hi
Press roller
