Duplo Duprinter DP-43S User Manual

168
z Exterior
chap.3
(4) Removing the Scanner Outer Cover
¡Left cover
1) Remove 2 screws to take out the cover.
¡Right cover
1) Remove 2 screws to take out the cover.
¡Rear cover
1) Remove the document cover.
2) Remove 4 screws to take out the cover.
Left cover
Screws
Screws
Right cover
\See page 164
Rear cover
Screws
Screws
43E00002
