139
b Press Section
chap.2
(2) Switching the Contact Pressure
The contact pressure can be switched on the operation panel, or automatically by a program. When it is
changed on the operation panel, the contact motor will start up to effect the switch as soon as the PRINT
key is pressed.
Circuits
Drum
Press roller
Lower limit switch
Contact pressure motor
Contact pressure motor
Maximum contact pressure limit switch
Low contact pressure limit switch
Hi contact pressure limit switch
Drive PCB unit
Main PCB unit
maximum limit switch
Hi limit switch
