15
Chap.1 x Specifications
DP-43E/DP-33E/DP-31E DP-43S/DP-33S/DP-31S
Display panel
320×240 dots, full dot matrix
LCD with Touch Panel (pressure
sensitive) input capabilities.
240×64 dots, full dot matrix LCD
Editing Functions
Trimming
Makeup
Photograph Mode, Reversing,
Masking, Outline Type, Halftones,
Background Designs, Reversing
Background Designs, Mask Area
Exchange, Addtional Makeup
Other standard functions
• OK monitor (graphical display,
Kanji characters/illustration
display)
• Memory ( 3 channels)
• Confidential Safeguard Function
• Entry of different number of
prints or sets
• Special function
• Fine start mode
• OK monitor (graphical display,
Kanji characters/illustration
display)
• Memory ( 2 channels)
• Confidential Safeguard Function
• Entry of different number of
prints or sets
• Special function
• Fine start mode
※ Specifications are subject to change without notice.
DUPRINTER DP-43E/DP-33E/DP-31E/DP-43S/DP-33S/DP-31S
Options
ADF (Automatic Document Feeder)
Drum unit ,A4 Drum(DP-43E/S)
Keycard counter (built-in type)
Tape cluster
Sorter
PC interface kit
PC interface kit
The printer driver must be installed in the PC.
• Compatible with Windows95 / Windows98
• Macintosh compatibility
(System 7.1 or later, MAC OS or later)
I/F board in main unit (on-line set III board unit)
SCSI cable (4 m)
※ Specifications are subject to change without notice.
• Specifications
• Option specifications
Vertical: up to 30
Y
above/below perpendicular
Horizontal: up to 30
Y
to either side of perpendicular
Input
By fingertip or special pen
Strength
Able to withstand maximum 29.4N (3kgf), a pplied
perpendicularly to the tablet surface for 1 minute
LCD
Recommended operating temperature: 0
Y4
40
Y
Recommended
viewing angle
range
To Next Page
