165
z Exterior
chap.3
5) Remove the connector(s).
• E type: 5 connectors
• S type: 1 connector
E type
(total 5 connectors)
Connector
2 connectors
Connector
Connector
Connector
S type
Hitch the hooks of the operation panel mounting
angles onto the plate springs in the frame.
Plate spring
Plate spring
Reinstallation
