c HELP Mode Function and Operation Procedures
chap.7
H-35
(1) Adjustment / specification settingHELP mode
1. Functions
Mode H-34 is not used
(1) Scanner leading edge sensing position adjustment
2. Operation procedures
Display Item Setting
0***
Sign flag
Moves to the left by the set
amount of the lower 3 digits.
1***
Moves to the right by the set
amount of the lower 3 digits.
*000
Set amount
Standard (initial value)
Maximum
*001
*010
*011
*100
*101
*110
*111
- L -
****
Correction amount display
During memorization:
(1) Scanner leading edge sensing position adjustment
q
Access HELP mode H-35, and press the PRINT key.
For the basic procedure for accessing HELP modes.
w
Use the [0] and [1] numeric keys to enter a 4-place binary value for
the desired correction amount. See the table below for 4-place
binary values and the corresponding correction amounts.
r
Press the STOP key. The HELP mode selection display will
reappear.
a To exit the HELP mode : Turn the power switch OFF.
a To access another HELP mode : Enter the desired mode number
using the numeric keys.
e
Press the [=] key. The correction amount will be memorized
in the battery PCB unit's EEPROM. During memorization, "-L-"
will be displayed.
Do not turn off the power before the "-L-" display has disappeared.
IMPORTANT
\See page 291
For Standards / Adjustment
\See page 242
Related HELP mode
HELP mode H-36 \See page 340
