Duplo Duprinter DP-43S - Page 348

348
c HELP Mode Function and Operation Procedures
chap.7
H-47, H-48
(1) Adjustment / specification settingHELP mode
1. Functions
Set width(mm)H-47H-48
0000 0000
Initial value
0000 0001
Set width
Converted desimal value for binary H-48 (upper 4
bits) + binary H-47 (lower 4 bits)
9
2 mm
Example : H-46 = 0111, H-45 = 1101
01111101 = 125
125
9
2 = 250
Set width = 250mm
Maximum value is 290mm.*
0000 0010
····· ·····
1001 0001
Maximum : 290mm
(1) Setting of special paper size width
The width of a special paper size is set using HELP modes H-47
and H-48. H-47 is used for the lower-order 4 bits of the setting, and
H-48 for the higher-order 4.
2. Operation procedures
****
¡H-47(Lower-order 4 bits)
(1) Setting of special paper size width
q
Access HELP mode H-47, and press the PRINT key.
For the basic procedure for accessing HELP modes.
w
Use the [0] and [1] numeric keys to enter a 4-place binary value for
the desired correction amount. See the table below for 4-place
binary values and the corresponding correction amounts.
\See page 291
e
Press the [=] key. The correction amount will be memorized
in the battery PCB unit's EEPROM. During memorization, "-L-"
will be displayed.
Do not turn off the power before the "-L-" display has disappeared.
IMPORTANT
- L -
During memorization:
* Platemaking width : 251mm (DP-33E/S, 31E/S).
Maximum value is 257mm (25136mm).
\See page 79
