3/3
2. Replacement and adjustment of parts
27440-5
27440-5
Order sorter section
If the length is not 9±1 mm, loosen five screws of the print sorter unit mount, and adjust the height of adjuster.
6. Connect the connectors and attach the connector cover. (three screws)
The connector J866 on the processor side is not used.
Screws
Adjustors
G090268
Connector cover
J/P820
J/P713
G081213
