Frontier LP7500 - Page 249

5/5
3. Mode
33004
33004
Processor Settings
17. Reconnect the hose of automatic cleaning pipe.
IMPORTANT
• Fit the hoses in the cutouts so that they will not be pinched by the processor top cover when it is closed.
• Be sure to connect the appropriate hose for each processing solution hose. If the hose is connected to other
processing solution hose, the replenishment is carried out to the different processing solution tank.
Cutout
G088972
