3. Mode
35320
35320
Maintenance
*4. When pressing Execute, Confirm whether to complete the air pulling out of the Cleaning Pump system piping. Cleaning water will be run
into the replenishing tank. Please refrain from draining for a long time. For details, refer to the manual. Would you like to operate the
Replenisher Cartridge Cleaning Pump? is shown.
*5. If the cleaning water gets into a tank, the amount of replenishment solution changes. Insert a hose into a cleaning nozzle and execute Output
Check without allowing any water to get in the tank.
When you insert a hose into the cleaning nozzle, we recommend you to operate Replenisher Cartridge Open Motor and move the replenishment
cartridge installation section to the lower position.
For details, see
☞27540.
*6. SP1: The menus marked with (SP1) in the table below are only shown when the service personnel password (2260) has been entered.
!
!!
! Dryer Section (common to all specifications)
!
!!
! Order Classification Section (common to all specifications)
*1. Shown only if the print sorter unit (10-inch type) is supported.
!
!!
! Colorimeter Unit (common to all specifications)
No. Display Status
1 Dryer Fan Press Execute to start, and Cancel to stop.
2 Dryer Heater 1 Press Execute to start, and Cancel to stop.
3 Dryer Heater 2 Press Execute to start, and Cancel to stop.
4 Dryer Heater 3 Press Execute to start, and Cancel to stop.
5 Dryer selection solenoid 1 Press Execute to operate once.
6 Dryer selection solenoid 2 Press Execute to operate once.
No. Display Status
1 Sorter Motor Press Execute to operate once.
2 Conveyor Motor
3 Manual Sorter Switch Lamp Press Execute to turn on, and Cancel to turn off.
4 Paper guide motor
*1
Press Execute to operate once.
5 Order Identification LED (Orange) Press Execute to turn on Order Identification LED (Orange).
6 Order Identification LED (Cyan) Press Execute to turn on Order Identification LED (Cyan).
No. Display Status
1 Paper Advance Motor Press Execute to start, and Cancel to stop.
2 Calibration Plate Advance Motor
3 Pressure Change Solenoid
4 Colorimeter Cooling Fan
