4/14
4. Troubleshooting
45530
45530
Error: Processor 2
No. 05534
Print Sorter Unit operation error.
Error message release
NO
Condition
Check Point
Diagnosis
$ Symptoms due to connection failure of wiring/symptoms resulted from blowout of fuse
NOTE
• To access the wiring diagrams, click Wiring diagrams in Bookmarks.
Suffix number Condition
00001 Although a specified time has passed since the print sorter unit started operating, the sorter home sensor does not
turn LIGHT.
00002 Although a specified time has passed since the sorter home sensor turned LIGHT, it does not turn DARK.
1 Clean the sorter home sensor using a blower brush.
Operation failure Manual No.
Sorter motor
☞63271
Processor I/O PCB 1 ☞66210
Processor control PCB ☞66200
Detection failure Manual No.
Sorter home sensor ☞63271
Processor I/O PCB 1 ☞66210
Processor control PCB
☞66200
Symptoms due to the wiring connection failure Symptoms of fuse blowout
− ☞4203 −
Distributed by: minilablaser.com
