4. Troubleshooting
45530
13/14
45530
Error: Processor 2
No. 05551
Paper Guide operation error.
Error message release
NO
Condition
Check Point
Diagnosis
NOTE
• To access the wiring diagrams, click Wiring diagrams in Bookmarks.
Suffix number Condition
1 Although the paper guide motor was operated in the direction which closes the paper guide, even after a specified
time has passed, the paper guide open sensor does not turn LIGHT.
2 After the paper guide open sensor turns LIGHT, the paper guide close sensor does not turn DARK even though a
specified time has passed.
3 Although the paper guide motor was operated in the direction which raises the paper guide, even after a specified
time has passed, the paper guide close sensor does not turn LIGHT.
4 After the paper guide close sensor turns LIGHT, the paper guide open sensor does not turn DARK even though a
specified time has passed.
5 Both the paper guide close sensor and paper guide open sensor turns DARK.
1 Clean the paper guide open sensor and paper guide close sensor using a blower brush.
Failed part Manual No.
Paper guide open sensor
☞63271
Paper guide close sensor
Paper guide motor
Processor control PCB
☞66200
Processor I/O PCB 1 ☞66210
