7/16
4. Troubleshooting
45900
45900
Error message: F replenishment
No. 05909[F]
Cartridge cleaning valve/Agitation solenoid valve is abnormal. P1R
No. 05910[F]
Cartridge cleaning valve cleaning valve is abnormal. P2RA
No. 05911[F]
Cartridge cleaning valve cleaning valve is abnormal. P2RB
Error message release
YES
IMPORTANT
• If the above error message is shown, do not click YES to close it and continue the printing process without performing the
diagnosis below.
After a set number of prints are output,
☞No. 05912[F] Predetermined process amount was exceeded. will be shown,
and then printing cannot be performed.
NOTE
• If printing process is continued after the above error is shown, the time is counted as Replenishment Lack Time and the P1R, P2RA
and P2RB replenishers will not be replenished.
Condition
Check Point
ERROR No. Condition
05909-00000 When the replenisher cartridge is cleaned, P1R cartridge flushing valve and P1R agitation solenoid valve are
opened and the auto cleaning pump is turned on for a specified time. However, P1R (Upper) Replenishment
Solution Level Sensor does not turn on.
05910-00000 When the replenisher cartridge is cleaned, P2RA cartridge flushing valve is opened and the auto cleaning pump
is turned on for a specified time. However, P2RA (Upper) Replenishment Solution Level Sensor does not turn
on.
05911-00000 When the replenisher cartridge is cleaned, P2RB cartridge flushing valve is opened and the auto cleaning pump is
turned on for a specified time. However, P2RB (Upper) Replenishment Solution Level Sensor does not turn on.
For details of operation specification, see ☞ 57010.
• For the QSS-3701/3702/3703/LP7500/LP7600, about 507 prints whose size is 127 mm × 89 mm can be processed after the error
occurs.
• For the QSS-3704/3705/LP7700/LP7900, about 545 prints whose size is 127 mm × 89 mm can be processed after the error occurs.
• If Initial Replenisher Operation (Auto Cleaning Pump)→Mixing Replenisher→Initial Replenisher Operation (Replenisher
Pump) in Processor Set Up Mode are not performed in order at system installation, the above errors may occur.
• The causes are shown below.
• If normal opening operation is performed at system installation, replenishment solution is created with the replenishment
tank empty. Then, the replenishment solution does not reach the position where P2RA (Upper) Replenishment Solution
Level Sensor and P2RB (Upper) Replenishment Solution Level Sensor turn on, and the above errors occur.
• If opening operation is performed in the Processor Set Up Mode at system installation, the above errors do not occur even
if P2RA (Upper) Replenishment Solution Level Sensor and P2RB (Upper) Replenishment Solution Level Sensor are off.
Countermeasure
1. Perform recovery procedure 1 from the replenishment error.
☞4610
Check the hoses for bends (Hoses connected to each of the cartridge cleaning valves and the auto cleaning pump).
Check the output amounts of auto cleaning pump + each automated cleaning valve again. ☞33004
Check the status of the replenishment solution level sensors of each processing solution with Input Check. ☞35220
