5/15
4. Troubleshooting
46000
46000
Error message: Printer 1
No. 06049
Pressure Guide operation error.
Error message release
NO
Condition
Check Point
Diagnosis
$ Symptoms due to connection failure of wiring/symptoms resulted from blowout of fuse
NOTE
• To access the wiring diagrams, click Wiring diagrams in Bookmarks.
Suffix number Condition
00000 The home position is not detected even though the pressure guide motor operated for a specified time.
1 Check that the pressure guide sensor is not soiled.
Operation failure Manual No.
Pressure guide motor ☞63090
Printer I/O PCB 1 ☞66020
Printer I/O PCB 3
☞66040
Printer control PCB ☞66000
Detection failure Manual No.
Pressure guide sensor
☞63090
Printer I/O PCB 3 ☞66040
Printer control PCB ☞66000
Symptoms due to the wiring connection failure Symptoms of fuse blowout
☞4202 − ☞4252
