4. Troubleshooting
46100
25/33
46100
Error message: Printer 2
No. 06194
Laser Control PCB control error.
Error message release
NO
Condition
IMPORTANT
• The error above may occur when the ARCNET communication status is not normal.
If the error occurs, check the following items.
• Check the ARCNET communication status on the Version Check display.
☞35500
• Check the ARCNET communication path.
☞50520
• For details about the diagnosis of ARCNET communication error, see ☞35940.
• Perform Printer I/F Main PCB Self-Diagnostic.
☞35930
Diagnosis
$ Symptoms due to connection failure of wiring/symptoms resulted from blowout of fuse
NOTE
• To access the wiring diagrams, click Wiring diagrams in Bookmarks.
Condition
A communication failure has occurred between the printer I/F main PCB and laser control PCB.
Suffix number Condition
00008 LVPECL does not communicate.
00009 When the connection is disconnected while receiving valid frame data
00010 When the valid frame data differs between the sending terminal and receiving terminal (e.g. data loss)
00011 When having received unspecified data
00012 When having received unspecified codes
Failed part Manual No.
Laser control PCB ☞66010
Printer I/F main PCB
☞66005
Symptoms due to the wiring connection failure Symptoms of fuse blowout
☞4202 −−
