5. Operation sequence
55110
2/4
55110
Paper advance operation
2. The paper guide in the paper supply unit A2 moves.
• Width change motor A2: ON/OFF
When the paper guide is on the home position
• It moves to the paper width of paper to be processed.
When the paper guide is at the different position from the paper width of paper to be processed
• The paper guide returns to the home position, and then it moves to the paper width of paper to be loaded.
When the paper width of paper to be loaded and that of paper processed just before it are same
• Goes to Step 3.
When the paper guide does not operate
• ☞ No. 06200-00001
Width Change Motor A2 operation error.
3. Advance roller A2 is pressured.
• Pressure release motor A2: ON
When the pressure release motor does not operate
• ☞ No. 06199-00001
Pressure Release Motor A2 operation error.
4. The paper is advanced.
• Paper magazine motor A2: ON
• Paper supply motor A/A2: ON
5. The paper passes through the paper end sensor.
When the paper end sensor A2 cannot detect any paper
• ☞ No. 06195-00001
Paper did not load. Paper Magazine A2
•
☞No. 06230-00001
Paper did not load. Paper Magazine A2
6. Specified length of paper is advanced until the paper edge reaches just before the advance roller A.
• Paper magazine motor A2: OFF
• Paper supply motor A/A2: OFF
7. The advance roller A2 repeats the pressure release/pressure twice.
• Pressure release motor A2: ON
When the pressure release motor does not operate
• ☞ No. 06199-00001
Pressure Release Motor A2 operation error.
8. The paper is advanced.
• Paper magazine motor A/A2/B/C: ON
• Paper supply motor A/A2/B/C: ON
Paper magazines A, B and C
Goes to Step 9.
