5. Operation sequence
55120
4/4
55120
Paper advance operation
Conditions other than above
Goes to Step 14.
13. Performs magazine initial operation.
Magazine initial operation is the operation that rewind the paper until the paper end sensor is not detected, and next advance
the paper to the position where it passed through the paper loading sensor again.
• Paper magazine motor A/B/C: ON/OFF
• Paper supply motor A/B/C: ON/OFF
If paper end sensor A/A2/B/C cannot detect the papers in rewinding paper and in re-advancing, and if
paper loading sensor cannot detect the papers in re-advancing
• ☞ No. 06012-00002
Paper did not load. Paper Magazine A
•
☞No. 06201-00002
Paper did not load. Paper Magazine A
•
☞No. 06013-00002
Paper did not load. Paper Magazine B
•
☞No. 06012-00002
Could not load the paper. Paper Magazine C
14. Paper is advanced to Arm unit 1 receiving position.
• Paper magazine motor A/A2/B/C: ON/OFF
• Paper supply motor A/A2/B/C: ON/OFF
• Paper advance motor 1: ON/OFF
When arm unit 1 is not on standby in receiving position
• The paper stays at the paper standby position until arm unit 1 comes down to its receiving position.
15. The loading is completed.
IMPORTANT
• If the paper advance length is 165.6 mm and more, paper cut operation is performed in paper supply
operation (arm unit 1 operation).
☞55200
