8. Appendix
80110
5/6
80110
Periodically replaced parts
Processor section (QSS-3705 [EC])
Processor section (PP7900/QSS-3705 [F])
Parts or checking items Description for maintenance Part No. Timing/Standard
replacement
timing
Quantity
Upper guide
Turn roller (EPDM) (No. 3
upper guide)
Check its damage or wear. If it is
damaged or worn, replace it with a new
one.
Check it every six months after three
years has passed. If necessary, replace it
with a new one.
A087423 Three years 3
Upper guide
Bearing (upper guide No.3)
Check its damage or wear. If it is
damaged or worn, replace it with a new
one.
Check it every six months after three
years has passed. If necessary, replace it
with a new one.
A032741 Two years 4
A032742 4
Upper guide
Gear (upper guide No. 3)
A050698 1
Upper guide
Bearing (upper guides No.5 to 8)
Check its damage or wear. If it is
damaged or worn, replace it with a new
one.
Check it every six months after three
years has passed. If necessary, replace it
with a new one.
A032741 Two years 4 each
A032742 4 each
Upper guide
Gear (upper guides No. 5 to 8)
A050698 1 each
Upper guide
Turn roller (squeegee roller)
Check its damage or wear. If it is
damaged or worn, replace it with a new
one.
Check it every six months after three
years has passed. If necessary, replace it
with a new one.
A083186 Three years 1
A087421 1
Upper guide
Bearing (squeezee roller)
Check its damage or wear. If it is
damaged or worn, replace it with a new
one.
Check it every six months after three
years has passed. If necessary, replace it
with a new one.
A032741 Two years 4
A032742 4
Upper guide
Gear (squeegee roller)
A050698 1
Processing rack section
Gear
Check its damage or wear. If it is
damaged or worn, replace it with a new
one.
Check it every six months after three
years has passed. If necessary, replace it
with a new one.
A050696 Two years 8
A050695 8
Processing rack section
Roller holder
A051198 8
Parts or checking items Description for maintenance Part No. Timing/Standard
replacement
timing
Quantity
Upper guide
Turn roller (EPDM) (No. 2
upper guide)
Check its damage or wear. If it is
damaged or worn, replace it with a new
one.
Check it every six months after three
years has passed. If necessary, replace it
with a new one.
A087423 Three years 2
B024363 1
Upper guide
Bearing (upper guide No.2)
Check its damage or wear. If it is
damaged or worn, replace it with a new
one.
Check it every six months after three
years has passed. If necessary, replace it
with a new one.
A032741 Two years 4
A032742 4
Upper guide
Gear (upper guide No. 2)
A050698 1
