8.13.3 CIRCUIT BREAKERS Tab
This CIRCUIT BREAKERS tab displays the status of all hardware and software CBs.
This tab is subdivided into two sections:
• HARDWARE CB
• SOFTWARE CB
Note: Software CBs cannot be reset by the flight crew.
8.13.3.1 HARDWARE CB
There are two kinds of hardware circuit breakers:
• Those that can be popped by the instructor and reset by the flight crew.
• Those that can be popped and tripped by the instructor but cannot be reset by the
flight crew.
Hardware CBs have the following statuses:
Indicates a circuit breaker that is not popped.
Indicates a circuit breaker that is popped by the instructor.
This CB can be reset by the flight crew.
Indicates a circuit breaker that is not popped/tripped.
Indicates a circuit breaker that is popped/tripped by the instructor.
This CB cannot be reset by the flight crew.
8.13.3.2 SOFTWARE CB
Software CBs have the following statuses:
Indicates a circuit breaker that is not tripped.
Indicates a circuit breaker that is tripped.
8.13.3.3 UNPOWERED Flag
Indicates that there is no electrical
current on the bus.
