A320 Neo Instructor Operating Station
Instructor User Guide
AIRCRAFT Tab
13 Oct 2017
Page 90
8.14 FAIL SUMMARY Sliding Panel
The FAIL SUMMARY sliding panel provides an overall status of:
• Armed and active malfunctions
• Popped/tripped circuit breakers
• Failed radio stations
As this sliding panel combines all types of active or armed failures, it allows the
instructor to easily manage and control all failures in the training session.
This sliding panel includes three tabs:
• MALFUNCTIONS
• CIRCUIT BREAKERS
• RADIO STATIONS
8.14.1 MALFUNCTIONS Tab
The MALFUNCTIONS tab displays a summary of all the active and armed
malfunctions. From this tab the instructor has the possibility to clear all active or
armed malfunctions or clear a single active or armed malfunction.
Listed malfunctions have the following statuses:
Indicates that the malfunction is armed and ready to be triggered in
the training session
Indicates that the malfunction is active in the training session.
8.14.2 CIRCUIT BREAKERS Tab
This CIRCUIT BREAKERS tab lists all the pulled, popped and tripped hardware and
software circuit breakers in the training session. The instructor has the possibility to
reset:
• A single CB
• All CBs in the training session.
