FSC A320 - Tabs and Interface Elements

A320 Neo Instructor Operating Station
Instructor User Guide
Control Board Workspace
13 Oct 2017
Page 18
4.1 Tabs and Interface Elements
The interface elements included in each tab of the Control Board are included in this
table.
Table 1 Control Board Interface Elements
Tabs
Section
Wheel Picker
Interface Element
Current
Conditions
Clouds
Tap to open sliding panel
Attitude Indicators
Tap to open sliding panel
Icing Conditions
Yes
Tap to open sliding panel
Turbulence
Tap to open sliding panel
A/C Wind
Text field
A/C OAT/ ISA Dev
Text field
Aircraft
GW
Yes
Text field
GW CG
Yes
Text field
Fuel
Yes
Text field
ZFW
Yes
Text field
ZFW CG
Yes
Text field
Malfunctions
Section showing number of
active/armed malfunctions
Data Link (DL)
Tap to open sliding panel
Communications (VHF)
Tap to open sliding panel
Weight & CG
Tap to open sliding panel
Services & Doors
Tap to open sliding panel
Malfunctions
Tap to open sliding panel
Circuit Breakers
Tap to open sliding panel
Fail Summary
Tap to open sliding panel
Reference
Airport
Airport & Runway
Yes
Tap to open sliding panel
Time of Day
Yes
Text field
Surface Wind
Yes
Tap to open sliding panel
Visibility
Yes
Text field
RVR
Yes
Tap to open sliding panel
Precipitation
Yes
Tap to open sliding panel
Clouds
Yes
Tap to open sliding panel
Temperature / ISA Dev
Yes
Text field
QNH
Yes
Text field
Microburst/ Windshear
Yes
Tap to open sliding panel
Runway condition
Yes
Tap to open sliding panel
