16.7.1.1.9 Exceedance Section
This section lists advisory level messages that correspond to the exceedances that
occurred during the record phase.
The color messages correspond to the advisory level color rules as dictated and found
in the Alpha-Beta and V-n Plot pages and appear in order of severity.
These messages can then be used for debriefing the student according to the severity
order.
Figure 176 Exceedances
16.7.1.2 CONTROLS Tab
This tab includes the necessary controls to:
• Display the UPRT SCENARIOS page
o To select Maneuver Based Training (MBT) or Scenario Based Training
(SBT) exercises
• Record the selected upset condition scenario
• Determine the number of dots (data points) that will be plotted on the graphs
• Insert markers on the recording
• Play back the recording for in-cockpit debriefing
Figure 177 CONTROLS Tab
