15.4.1.2.4 Tail Clearance
The Tail Clearance graphs allow the instructor to evaluate and assess the tail
clearance to avoid a tail strike by monitoring five graphs:
• Airspeed
• Radar Altitude
• Tail Clearance (inches)
• Pitch Attitude
• Pitch Rate
Figure 135 Tail Clearance Graphs (Typical)
